WILLSTRONG® T-ZCP Titanium-Zinc Composite Panel

Product Introduction

The WILLSTRONG® T-ZCP Titanium-Zinc Composite Panel combines the natural metallic appearance and patina characteristics of titanium-zinc with a composite core designed for structural rigidity, flatness and durability.

The titanium-zinc facing develops a distinctive natural finish over time and offers self-healing characteristics associated with the formation of a protective patina. Unlike conventional coated metal panels that depend on an artificial PVDF finish for their visual character, T-ZCP is designed to preserve the natural appearance of titanium-zinc while providing a lightweight composite panel structure.

The panel is suitable for premium ventilated façades, roofing, eaves, shading elements, signage, storefronts and architectural landmark projects. Its combination of flatness, rigidity, acoustic performance, fire-rated core options and weather resistance provides flexibility for demanding architectural applications.

WILLSTRONG® supplies T-ZCP titanium-zinc composite panels for architectural projects requiring natural metallic aesthetics, long-term durability and versatile fabrication.

Key Product Advantages

1. Natural Titanium-Zinc Finish

The titanium-zinc outer layer provides a distinctive metallic appearance that can develop naturally with exposure. Its patina contributes to an evolving architectural finish and supports the material's natural corrosion protection characteristics.

2. Self-Healing Patina

Titanium-zinc can develop a protective patina over time. This natural surface process provides self-healing corrosion resistance and helps the panel maintain its appearance and performance under atmospheric exposure.

3. High Strength and Rigidity

The composite construction combines metal facing layers with a lightweight core to achieve high structural rigidity. The specified section modulus is 1.88 cm³/m and rigidity is 3080 kNcm²/m.

4. Excellent Flatness

The composite structure is designed to maintain excellent panel flatness. This characteristic is particularly valuable for large architectural surfaces where visual uniformity and smooth transitions are important.

5. Fire-Rated Core Options

T-ZCP can be configured with different core constructions and corresponding fire ratings. The supplied specifications include A2-s1,d0 and B-s1,d0 configurations under EN13501-1.

The A2 configuration uses a non-combustible mineral-filled core, while the B1 configuration uses a flame-retardant mineral-filled core with halogen-free flame-retardant additives.

6. Acoustic Performance

The composite structure provides sound damping and acoustic insulation characteristics. The specified sound transmission loss is ≥25 dB, while the sound absorption factor is 0.05.

7. Corrosion Resistance

The titanium-zinc surface provides natural resistance to atmospheric corrosion. Additional coating performance data also demonstrates resistance to salt spray, acids, solvents, moisture and accelerated weathering under the specified test conditions.

8. Versatile Design Options

T-ZCP is available in natural and pigmented titanium-zinc finishes, providing options for different architectural concepts and façade designs.

9. Custom Dimensions

Standard panel thicknesses include 4 mm, 5 mm and 6 mm. The panel width is available at 1000 mm, with custom cut lengths and custom dimensions available upon request.

10. Suitable for Multiple Building Surfaces

The panel can be used for façades, roofs, eaves and shading elements. Its lightweight composite construction also supports fabrication into architectural details and transitions.

Product Structure

The T-ZCP composite panel consists of a titanium-zinc facing layer, composite core and surface treatment system.

The supplied physical specifications identify titanium-zinc/aluminum layer thicknesses of 0.7/0.5 mm depending on the construction. Core options include mineral-filled polymer configurations, while the surface may incorporate lacquering or patina finishes.

The panel construction is designed to combine the visual characteristics of titanium-zinc with the dimensional stability and structural properties of a composite panel.

Dimensions & Size

Item	Specification
Panel Thickness	4 mm / 5 mm / 6 mm
Metal Sheet Thickness	0.7 mm
Standard Width	1000 mm
Other Width	1250 mm according to physical property data
Length	Custom cut length
Custom Dimensions	Available upon request
Titanium-Zinc/Aluminum Layer	0.7 / 0.5 mm
Core	Mineral-filled polymer

Color and Finish Options

The T-ZCP range includes natural and pigmented titanium-zinc finishes:

• NATURAL VM ZINC

• PIGMENTO BLUE

• QUARTZ-ZINC

• PIGMENTO RED

• ANTHRA-ZINC

• PIGMENTO GREEN

• AZENGAR

• PIGMENTO BROWN

The finish selection allows architects and project designers to coordinate the panel appearance with different façade, roofing and architectural design concepts.

Fire Performance

Different T-ZCP constructions are available with different fire performance classifications.

Standard	Fire Rating / Result
EN13501-1	A2-s1,d0
EN13501-1	B-s1,d0
DIN4102-7	Passed
BS476-Part 6	Fire propagation index = 1.0
BS476-Part 7	Class 0
NFPA285	Passed
ASTM E84-15a	Flame Spread Index 5; Smoke Developed Index 0
GB 8624-2012	A2-s1,d0
GB 8624-2012	B-s1,d0
GOST31251	Passed

The applicable fire classification depends on the selected panel construction. Project specifications should be confirmed against the required local building code and tested configuration.

Physical Properties

Property	Specification
Panel Thickness	4 mm configuration shown in supplied data
Weight	10.4 kg/m² for FR-B,s1,d0; 11.1 kg/m² for FR-A2,s1,d0
Width	1000 / 1250 mm
Section Modulus	1.88 cm³/m
Rigidity	3080 kNcm²/m
Alloy / Temper	EN988 titanium-zinc / Aluminum 3003H26
Modulus of Elasticity	≥80,000 / 70,000 N/mm²
Tensile Strength	≥150 / 130 N/mm²
0.2% Proof Stress	≥120 / 90 N/mm²
Elongation	35% / 5%
Linear Thermal Expansion	2.2 mm/m at 100°C

Surface and Coating Properties

The panel can use lacquering or natural patina surface treatments. The supplied data specifies:

Property	Specification
Film Thickness	≥16 μm
Initial Gloss	15–50
Hardness	HV61
Color Difference, Same Batch	ΔE ≤2.0
Color Difference, Same Color Code	ΔE ≤3.0
Impact Resistance	≥50 kg·cm
Pencil Hardness	≥2H
Adhesion	Class 0
Abrasion Resistance	≥5 L/μm
Salt Spray Resistance	Class 1 or better

Weather and Chemical Resistance

The supplied performance data indicates resistance to several environmental and chemical exposure conditions.

Hydrochloric Acid Resistance

No blistering, chalking, blushing or pitting corrosion is specified on the panel surface, with aged color difference of ΔE ≤3.0.

Nitric Acid Resistance

No blistering or other specified surface changes are indicated, with color difference of ΔE ≤5.0.

Solvent Resistance

For PVD and PVDF surfaces, the specified result includes no substrate exposure, blushing or dissolution.

Mortar Resistance

No change is specified under the supplied mortar resistance test.

Accelerated Weathering

The specified performance includes color difference ΔE ≤3.0, chalking class 0, no cracking, peeling or flaking, and gloss retention of ≥60%.

Damp Heat Resistance

The supplied test results indicate no coating blistering, no delamination of the honeycomb adhesive bond and no white-rust exudation from the titanium-zinc substrate.

Boiling Water Resistance

The coating is specified to show no blushing, blistering or peeling, while the composite bond shows no delamination.

Acoustic Properties

The composite panel provides acoustic performance suitable for architectural envelope applications.

Property	Specification
Sound Absorption Factor	0.05
Sound Transmission Loss	≥25 dB

The actual acoustic performance of a completed façade or roof system depends on the panel configuration, supporting structure, joints and overall building envelope design.

Thermal Properties

Property	Specification
Thermal Resistance	0.09 m²·K/W
Thermal Conductivity	0.44 W/m·K
Heat Transfer Coefficient	5.58 W/m²·K
Temperature Resistance	-50°C to 80°C

Actual thermal performance in a building envelope depends on the complete façade or roofing assembly, including insulation, air gaps, support systems and joints.

Application Areas

Ventilated Facades

T-ZCP can be used as an exterior cladding material for premium ventilated façade systems. Its natural metallic appearance and flat composite construction support contemporary architectural designs.

Roofing

The titanium-zinc composite panel can be used for roofing applications requiring a durable metallic appearance combined with lightweight composite construction.

Eaves

T-ZCP can be fabricated for eave details and edge conditions, allowing the architectural finish to continue across different building surfaces.

Shading Elements

The panel can be incorporated into architectural shading elements where lightweight construction, durability and coordinated façade aesthetics are required.

Signage and Storefronts

Standard panel configurations provide workability for signage and storefront applications where a refined metallic finish and easy processing are required.

Design and Fabrication

The composite structure combines a titanium-zinc facing layer with a lightweight core to provide a balance between rigidity and workability.

Custom cut lengths are available, and custom dimensions can be requested for project-specific requirements. Fabrication should be performed using appropriate equipment and procedures for titanium-zinc composite panels.

The selected panel thickness, core construction, surface finish and dimensions should be determined according to the project's structural, fire, aesthetic and installation requirements.

Architectural Project Reference

Brown University – Granoff Center for the Creative Arts

WILLSTRONG® supplied titanium-zinc composite panels for the Granoff Center for the Creative Arts at Brown University.

The project demonstrates the use of titanium-zinc composite panels in a contemporary architectural environment. The natural patina provides an evolving visual character and corrosion protection, while the lightweight composite construction supports design flexibility and long-term durability.

The application highlights the suitability of titanium-zinc composite panels for creative architectural projects requiring a distinctive metallic appearance and durable building envelope solution.

Selection Considerations

When selecting T-ZCP for an architectural project, buyers and designers should confirm:

• Required panel thickness

• Required fire rating

• Core construction

• Titanium-zinc finish

• Panel width and length

• Building façade or roofing application

• Structural and rigidity requirements

• Acoustic requirements

• Thermal requirements

• Local building code requirements

• Installation and fabrication method

The final specification should be selected according to the project design and applicable testing requirements.

B2B Supply Information

WILLSTRONG® provides titanium-zinc composite panels for architectural façades, roofing and building envelope applications.

T-ZCP is available in 4 mm, 5 mm and 6 mm thicknesses, with multiple natural and pigmented finishes and custom cut lengths. Different core configurations can be selected according to fire performance and project requirements.

For project procurement, buyers can provide the required dimensions, fire rating, finish, application area and quantity when requesting product information or samples.

Product Summary

Combining natural titanium-zinc aesthetics, self-healing patina characteristics, composite rigidity, acoustic performance and multiple fire-rated core options, the WILLSTRONG® T-ZCP Titanium-Zinc Composite Panel is designed for premium façades, roofing, eaves, shading and other architectural applications.

Its range of thicknesses, finishes and custom dimensions provides flexibility for architectural design and project fabrication.

For titanium-zinc composite panel procurement and building envelope projects, WILLSTRONG® can provide T-ZCP solutions according to project-specific design and performance requirements.

WILLSTRONG® T-ZCP Titanium-Zinc Composite Panel provides a natural metallic finish with composite performance for durable architectural applications.
