Six Axis Industrial Robot BRTIRUS3511A
Six Axis Robot BRTIRUS3511A
Arm span: 3500mm
Load: 100kg
Six Axis Handling Robot Product Details
BRTIRUS3511A is a six-axis robot developed by Bronte for certain monotonous, frequent and repetitive long-term operations, or operations in dangerous and harsh environments. It has a 3500mm arm span and a maximum load of 100kg. With the flexibility of multiple degrees of freedom, it can freely handle scenarios such as loading and unloading, handling, and palletizing. High protection level: IP50, dust proof. High precision: Repeat positioning accuracy ±0.2mm.
Main Specification
Arm span (mm): 3500
Repeat positioning accuracy (mm): ±0.2
Maximum load (KG): 100
Power capacity (KVA): 28
Weight (KG): about 1350
|
Project |
Scope |
Maximum Speed |
|
|
Arm |
J1 |
±160° |
85°/S |
|
J2 |
-75°/+30° |
70°/S |
|
|
J3 |
-80°/+85° |
70°/S |
|
|
Wrist |
J4 |
±180° |
82°/S |
|
J5 |
±95° |
99°/S |
|
|
J6 |
±360° |
124°/S |
|
No further notice if the specification and appearance are changed due to improvement and other reasons. Thank you for your understanding.
