GL-206096-FLS-1DSDR-2SSDL-2P

The GL-206096-FLS-1DSDR-2SSDL-2P Multi-Mode Transport Storage Container is a heavy-duty modular storage solution developed on the GreenLite® base platform. It is specifically designed for convenient transportation by forklift, truck, and other intermodal shipping methods.

A complete unloading kit is supplied as standard, making the container easier to position, relocate, and deploy at different job sites. The unit features a three-compartment interior with a practical 50% / 25% / 25% space distribution, providing separate storage areas for different equipment, tools, inventory, or materials.

The container is equipped with a combination of one double access door and two single access doors, finished in custom Janus Smart Blue. Its construction incorporates lightweight reinforced steel panels, waterproof anti-slip flooring, screened ventilation, weather-sealing components, and durable locking hardware.

This configuration makes it suitable for industrial facilities, construction sites, logistics centers, commercial self-storage applications, remote work locations, and outdoor storage yards.

GreenLite® Base Construction & Dimensions

The container is engineered around a standard GreenLite® heavy-duty load-bearing base, providing a stable foundation for transportation and storage applications.

• Overall external dimensions: 19 ft L × 60 in W × 96 in H

• Heavy-duty GreenLite® structural base frame

• Integrated forklift sleeves designed for efficient handling and transportation

• Sleeve centerline spacing: 965 mm

• Internal forklift sleeve opening: 100 mm H × 305 mm W

• Centered support runners are installed beneath the base

• Support runners are precisely aligned with the bottom plates of the forklift sleeves for balanced lifting and even load distribution

• A complete unloading kit is included as standard for convenient on-site unloading and relocation

The integrated lifting and unloading structure allows the container to be moved efficiently while maintaining stability during transportation and placement.

Exterior Panels, Frame & Color Options

The exterior walls are manufactured from 0.50 mm lightweight FLS steel panels, providing a balance between durability and reduced overall weight.

The main structural components feature a consistent white finish, including:

• Base frame

• Impact-resistant corner guards

• Exterior wall panels

• Wall framing

• Door frames

• 30 mm pitched roof

For a distinctive appearance and brand-oriented design, all access doors are finished in Janus Smart Blue, Pantone PMS 7688C.

The combination of white structural components and blue access doors creates a clean, professional appearance suitable for commercial and industrial environments.

Pitched Roof & Weather Protection

The container uses a 30 mm pitched roof designed to promote faster rainwater runoff and minimize the risk of water accumulation on the roof surface.

Several factory-installed sealing components are included to improve weather resistance:

• New top wall gaskets

• Hole snap caps for panel joints and fastener openings

• Three rain shields installed above the access doors

These components help reduce the entry of dust, moisture, and outside air through joints and openings.

For applications requiring a higher level of airtightness and water resistance, optional sealing accessories are also available at an additional charge, including:

• Rubber door gaskets

• Roof mounting washers

• Wall mounting washers

These optional components allow the container configuration to be adapted to different environmental and storage requirements.

Waterproof Anti-Slip Flooring

The flooring system is designed to provide reliable protection for stored goods while supporting everyday loading and unloading activities.

A 19 mm plywood core forms the main floor structure. Both the upper walking surface and the underside of the floor are covered with slip-resistant, waterproof laminated protective layers.

This dual-sided waterproof construction helps isolate stored materials from ground moisture. At the same time, the anti-slip surface provides a safer walking and working area during the loading, unloading, and movement of goods inside the container.

Door Configuration & Locking System

The container incorporates three independent access points to match its three-compartment internal design.

Door Arrangement

1. One standard USC double side door is positioned on the right side of the long wall. This DSDR door is equipped with a heavy-duty stainless steel locking assembly.

2. Two standard single side doors are installed on the left side of the long wall. Each 2SSDL door has its own stainless steel locking assembly.

This arrangement provides direct access to each storage section while maintaining the overall security of the container.

Door Retention System

Each access door is equipped with a dual stainless steel T-slot door holder/catch mechanism.

Three complete sets are factory-installed to keep the doors securely open during loading and unloading. The retention system helps prevent unwanted door movement or accidental swinging, making daily operation more convenient and efficient.

Three-Compartment Internal Layout

Two full-height corrugated steel partition walls divide the internal space into three independent storage compartments.

The internal capacity is arranged in a 50% / 25% / 25% configuration, providing a practical solution for classified storage.

This compartmentalized structure is especially useful when different types of equipment, tools, materials, or inventory need to be stored separately. It can help simplify inventory organization, improve access to individual storage areas, and reduce the risk of different materials being mixed together.

The combination of separate compartments and independent access doors provides greater flexibility than a conventional single-space storage container.

Screened Ventilation System

To support airflow inside the enclosed storage areas, the container incorporates screened ventilation openings.

Protective insect and debris screens are fitted to the vents to help prevent unwanted outdoor materials from entering the storage compartments.

The ventilation design promotes air circulation and helps reduce condensation inside the container while providing protection against rainwater, insects, and outdoor debris.

Ventilation is incorporated throughout the compartment structure so that the individual storage zones can maintain suitable internal airflow.

Key Product Advantages

The GL-206096-FLS-1DSDR-2SSDL-2P combines transportation flexibility, segmented storage, weather protection, and practical daily operation in one modular container.

1. Multi-Mode Transportation

Integrated forklift sleeves and the standard unloading kit make the container suitable for transportation and relocation by forklift, truck, and other compatible logistics methods.

2. Three Independent Storage Zones

The 50% / 25% / 25% internal layout provides three dedicated storage compartments, supported by a combination of double and single access doors.

3. Waterproof & Anti-Slip Floor

The 19 mm plywood floor with dual-sided waterproof laminated protection helps protect stored materials from ground moisture while providing a slip-resistant surface for daily use.

4. Professional Custom Appearance

The white structural finish is combined with Janus Smart Blue doors in Pantone PMS 7688C, creating a clean and recognizable industrial appearance.

5. Durable Locking & Door Retention Hardware

Heavy-duty stainless steel locking assemblies provide secure access control, while T-slot door holders keep doors firmly open during loading and unloading.

6. Screened Ventilation

Ventilation openings with protective screens support internal air circulation, helping reduce condensation while limiting the entry of insects and outdoor debris.

7. Lightweight Steel Panel Construction

The 0.50 mm FLS steel panels provide a practical balance between structural strength and reduced weight, which can be beneficial for transportation and logistics.

8. Optional Weather-Sealing Upgrades

Additional door gaskets, roof washers, and wall washers are available for applications where enhanced waterproofing and airtight performance are required.

20' Portable Storage Container Units / House

The GL-206096-FLS-1DSDR-2SSDL-2P is part of the portable storage container category and can be used for a wide range of temporary or long-term storage requirements.

Its modular structure, transportation-ready base, multiple access doors, internal partitions, ventilation system, and weather-resistant construction make it a flexible option for industrial, commercial, construction, and remote-site applications.
