FGNEX-Double Glass Bifacial-430W-445W

1500-V System Voltage, Lower BOS Cost;
Annual Degradation <0.5%,30-year Linear Performance Warranty;
Frameless Design, Easier Surface Cleaning,

Introduction


   FGNEX Double glass panels (BIPV-Building Integrated Photovoltaics) are suitable for steel frame structures, which are flexible and easy to install. With beautiful appearance, and also environmentally friendly.

Feature

   OptimizedPower Gain


   High Resistance to PID;


   Low Risk of Micro-cracks; Zero Snail Trails Probability;

Higher-Than-Ever ROI


   1500-V System Voltage, Lower BOS Cost;


   Annual Degradation <0.5%,30-year Linear Performance Warranty;


   Frameless Design, Easier Surface Cleaning,

Design


   Unique Layout design to match the adhesive installation


   Unique design can meet the sunroom's requirements with excellent light transmittance and waterproof.

Working Condition


   Working Condition Compatibility & Safety


   High Resistance to High Temp, High Humidity, Sand, Acid and Alkali Environment;


   2400Pa Snow Loading,2400Pa Wind Loading;


   Class-A Fireproofing;

Parameter
ELECTRICAL CHARACTERISTICS
Model BPDMJ72H(S)-430 BPDMJ72H(S)-435  BPDMJ72H(S)-440 BPDMJ72H(S)-445
STC NMOT STC NMOT STC NMOT STC NMOT
Maximum Power at STC [Pmax] [W] 430 321 435 325 440 329 445 333
Open Circuit Voltage [Voc] [V] 48.79 45.6 49.01 45.8 49.29 46.0 49.54 46.3
Short Circuit Current[lsc] [A] 11.18 9.02 11.24 9.06 11.29 9.10 11.33 9.14
Voltage at Maximum Power point[Vm] [V] 40.47 37.2 40.76 37.4 41.06 37.7 41.33 37.9
Current at Maximum Power point[lm] [A] 10.63 8.65 10.67 8.69 10.72 8.73 10.77 8.77
Power Tolerance [%] 0~+3%
Module Efficiency [%] 19.4 19.7 19.9 20.1
STC:Air Mass AM1.5,Ir-radiance 1000W/m Cell temperature 25℃. NMOT:Air Mass AM1.5,Ir-radiance 800W/mAmbient tempera-ture 20'C,wind speed 1m/s.
DOUBLE SIDES POWER OUTPUT(BACK GAIN)
5% Maximum Power [W] 445 450 455 461
10% Maximum Power [W] 460 465 471 476
15% Maximum Power [W] 475 481 486 492
20% Maximum Power [W] 490 496 502 507
Notes: Spectrum AM1.5, Irradiance Gcomp, Temperature 25℃.Gcomp=(1+Albedo*Bifaciality)*1000W/m2 Bifaciality=Min(lsc_rear/lsc_front,Pmpp_rear/Pmpp_front)
WORKING CONDITIONS TEMPERATURE COEFFICIENTS
Maximum System Voltage(With S) [V] 1000 DC(IEC)
Maximum System Voltage(Without S) [V] 1500 DC(IEC)
Operating Temperature [℃] -40~+85
Nominal Operating Cell Temperature [℃] 45±3
Maximum rated current [A] 20
Temperature Coefficient
Temperature Coefficient of Pmax [%/℃] -0.42
Temperature Coefficient of Voc [%/℃] -0.33
Temperature Coefficient of lsc [%/℃] 0.04
MECHANICAL SPECIFICATIONS
Cell Type  Mono crystalline
Solar Cells 144(6*24)
Module Dimension [mm] 2111*1046*30mm
Weight[Kg]  27
Front Glass [mm]  2.0 Semi tempered coated glass
Interlayer  EVA/POE/PVB
Back Glass[mm]  2.0 Semi tempered glass
Junction Box  Ip67 Rated,3 by-pass diodes
Connector Multi-Contact MC4(or equivalent)
Frame 30mm Aluminum Frame
Maximum Load
Capacity[Pa]
2400(wind load)/2400(snow load)
Package Configuration 40'HQ 770 pieces
