CNC Trimming Machine HBL-ACTA-B

Full Automatic Clear Aligner Production Line

The Full Automatic Clear Aligner Production Line is designed to provide a complete digital manufacturing solution for clear aligners. From film roll feeding to thermoforming, laser marking, trimming, and finished product output, the system delivers a fully automated workflow that minimizes manual labor while improving production efficiency, accuracy, and consistency.

Ideal for orthodontic laboratories and clear aligner manufacturers, this production line supports continuous, high-volume manufacturing with stable quality and intelligent automation.

Key Features

Fully Automated Production Workflow

The upgraded system integrates automatic film cutting to create a complete closed-loop production process from film roll to finished aligners. This significantly reduces manual intervention and improves production efficiency.

Automatic Teeth Mold Feeding

The intelligent feeding system accommodates 96 teeth molds (4 × 24) and supports continuous unattended operation for approximately one hour. Equipped with a vision recognition system, each mold is accurately identified and positioned before processing.

High-Precision Thermoforming

The thermoforming unit provides uniform heating and softening of film materials with an adjustable temperature range of 0–700°C, ensuring excellent adaptation and a precise fit for clear aligners.

Robotic Precision Trimming

An ABB 6-axis industrial robot performs automatic trimming with millimeter-level precision. The robot maintains outstanding consistency while accurately processing complex curves and irregular aligner shapes.

Flexible Marking System

The integrated laser marking module supports multiple identification formats, including:

• Serial numbers

• Letters

• Barcodes

• QR codes

• Company logos

This improves product traceability and manufacturing management.

Technical Specifications

Function Modules

• Automatic teeth mold feeder

• Thermoforming unit

• Laser marking system

• Blade trimming system (optional laser trimming)

Robot Specifications

Spindle Specifications

Advantages of the New Generation Model

Compared with the previous generation, the upgraded production line delivers higher productivity, greater automation, and improved processing flexibility.

Why Choose This Production Line?

• Fully automated production from film roll to finished aligners

• Reduced labor costs and operator intervention

• Stable, high-speed production with up to 120 aligners per hour

• ABB robotic trimming ensures exceptional cutting accuracy

• Vision-guided positioning improves manufacturing precision

• Compatible with multiple film formats for greater production flexibility

• Suitable for large-scale orthodontic laboratories and clear aligner manufacturers
