Carbon Steel & Stainless Steel Clad Plate
Metallurgically bonded double-stainless clad plate, matching different stainless grades to balance ultra corrosion resistance, high strength & raw material cost savings.
Carbon Steel & Stainless Steel Clad Plate
Metallurgically bonded bimetallic plate combining carbon steel structural strength & stainless steel anti-corrosion performance, cost-effective alternative to solid stainless steel. Manufactured via hot roll bonding, fully customizable for pressure vessel, chemical, desulfurization & marine projects.
·Base Substrate: Q235B carbon structural steel, Q355B low alloy high strength steel, Q345R pressure vessel steel
·Cladding Layer: 304/L, 316L, 2205,2507 duplex stainless steel, 904L, 321, 310S
Custom thickness ratio of substrate & cladding layer is available per drawing requirements.
Main Stainless Steel Clad Carbon Steel Plates
| Single-sided Clad | Double-sided Clad | ||||||
| 304+Q235 | 304+Q235+304 | ||||||
| 304L+Q235 | 304L+Q235+304L | ||||||
| 316+Q235 | 316+Q235+316 | ||||||
| 316L+Q235 | 316L+Q235+316L | ||||||
| 310S+Q235 | 310S+Q235+310S | ||||||
| 321+Q235 | 321+Q235+321 | ||||||
| 2205+Q235 | 2205+Q235+2205 | ||||||
| 2507+Q235 | 2507+Q235+2507 | ||||||
| 904L+Q235 | 904L+Q235+904L | ||||||
| 304+Q355 | 304+Q355+304 | ||||||
| 304L+Q355 | 304L+Q355+304L | ||||||
| 316L+Q255 | 316L+Q355+316L | ||||||
| … | … |
Product Specifications：
| Cold-rolled | Hot-rolled | Heavy plate | ||||||
| Thickness (mm) | 0.5-3.0 | 3.0-14.0 | 6.0-120.0 | |||||
| Width(mm) | 1030/1250/1530 | 1030/1250/1530 | 1000-3000 | |||||
| Cladding Ratio | 10%+80%+10%/5%+90%+5% or customized | 1+4/1+5/1+7/1+9/1+11/10%+80%+10%/5%+90%+5% or customized | 5%-50% | |||||
| Standard | ASTM A264，EN 13445-2 ，JIS G3601 ，GB/T 8165 | |||||||
Production & Quality Control
·Production line：Hot rolling composite workshop, support bulk order & small trial order
·Full inspection standard: Ultrasonic testing (UT) for bonding quality, mechanical tensile / bending test, chemical composition analysis, hardness inspection
·Certifications available: SGS, BV, TUV third-party testing report, material test certificate (MTC)
·Packing: Waterproof plastic film + wooden pallet, sea-worthy export package to avoid rust during long ocean transportation
Main Industrial Applications
Pressure Vessel & Heat Exchanger: Reactors, storage tanks, distillation towers, heat exchange equipment for petrochemical plants
Environmental Protection Equipment: Flue gas desulfurization towers, sewage treatment tanks, waste acid recovery devices
Marine & Desalination: Seawater desalination containers, offshore platform structural liners, ship corrosion-resistant compartments
Pulp & Paper Industry: Bleaching tanks, corrosive medium processing equipment
Food & Pharmaceutical: Hygienic reaction kettles, food storage containers, stainless inner lining structures
Power & Metallurgy: Boiler liners, high-temperature corrosion resistant equipment, metallurgical reaction furnaces
